GH-101-J
thru
GH-101-JSI


  • Heavy Duty
  • Two Stops Provide User with a Choice of Handle and Bar Movement.
  • HOLDING CAPACITY : 550 kg MAX.
    WEIGHT : 2540g
    HANDLE MOVES 48o, BAR 100o
    *Accepts all 5/8-11 diameter spindles.
    U-Bar supplied with flange washers.
    Solid bar supplied with bolt retainer.
    All models supplied with GH-SA-58500 and red vinyl hand grip.
    *Supplied with hardened bushings.
    *Removable ground pins.
MODEL DESCRIPTION
GH-101-J U-BAR,FLANGED BASE,STRAIGHT HANDLE
GH-101-JS SOLID BAR,FLANGED BASE,STRAIGHT HANDLE
GH-101-JSB U-BAR,STRAIGHT BASE, STRAIGHT HANDLE
GH-101-JSI SOLID BAR,STRAIGHT BASE,STRAIGHT HANDLE
